SanStar™ WS-3A Medical Computer Motherboard on Android, IEC 60601 Compliant
OverviewWaterproof Triage Tag Desinfectable with Graphic Legend 8 x 4 inch for Emergency Medical Technician, First Respond, Field Medic, Rescue and Relief Highlights
|
eHealth | Medical Computer | Hospital Computer | Medical Imaging | Medical Device | Infotainment System | Medical Panel | Surgical Video Stream
|
The new embedded Android motherboard SanStar WS-3A is developed from the platform of Warp 3 Medical Recorder to creates a broad ecosystem for the next generation medical device. The goal is that engineers can connect their own modules to the motherboard via 2 x RS232, 8 x USB and other 20 different types of interfaces. With its exceptional designs, the SanStar WS-3A works to two independent display or one 4K resolution screen. It has been designed specially for smart devices, medical imaging and communication with performance-intensive applications at the minimum R&D cost and pre-market time. Regulatory Conformity
|
Major Specifications |
|
|
CPU |
RK3288 Quad-core Cortex-A17 @ 1.8GHz |
| GPU | ARM Mali-T764 GPU with TE, ASTC, AFBC, support for OpenGL ES 1.1/2.0 /3.0, OpenVG1.1, OpenCL, Directx11 |
| Memory | DDR3 2GB/4GB |
| Storage | EMMC FLASH 8GB/16GB/32GB |
| Supports TF card @ max. 32GB | |
| Operating system | Android 5.1 |
| Communication | RJ45 100M isolated LAN port |
| 2.4G/5G WIFI 802.11 a/b/g/n | |
| V2.1+EDR/Bluetooth 3.0/3.0+HS/4.0 | |
| Mobile Network | Supports LTE-TDD/LTE-FDD/TD-SCDMA/CDMA/EDGE/GPRS/GSM modules |
| Display output | eDP, LVDS (single, 6-bit dual, 8-bit, 10-bit dual), MIPI, HDMI 2.0 supports display @ max. 3840 x 2160 pixels |
| Interfaces | 7 x USB OST, 1x USB OTG, 2 x RS232 |
| 1 x SIM Slot | |
| 4 x custom I/O ports | |
| Supports USB/MIPI cam, up to 13MP | |
| Supports infrared, BT remote control | |
| 1 x Infrared sensor interface | |
| Audio input, output, MIC interfaces | |
| 3 x custom key interfaces | |
| 1 x 12V Cooling fan interface | |
| 1 x Screen backlight control interface | |
| 3 x indicator interfaces (power, working status, custom) | |
| Dimension | 145(L) x 90(W) x 22(H) mm |
| Weight | 99.27g |
Variant
|
|
WS-3.208A |
WS-3.216A |
WS-3.232A |
WS-3.408A |
WS-3.416A |
WS-3.432A |
|
DDR3 Memory |
2GB | 2GB | 2GB | 4GB | 4GB | 4GB |
|
EMMC FLASH Storage |
8GB | 16GB | 32GB | 8GB | 16GB | 32GB |
Verified Compatible Modules
Generic USB Mouse & Keyboard
Generic Bluetooth Mouse & Keyboard
Screen
|
Size |
Resolution |
Type of Interface |
| 7" | 1280 x 800 | MIPI |
| 8" | 1024 x 768 | LVDS |
| 10.1" | 1280 x 800 | LVDS |
| 10.1" | 1280 x 800 | MIPI |
| 10.1" | 2560 x 1600 | eDP |
| 15" | 1024 x 768 | LVDS |
| 21.5" | 1920 x 1080 | LVDS |
Touch Panel
|
Type |
Size |
Resolution |
Type of Interface |
| Capacitive | 7" | 1280 x 800 | USB |
| Capacitive | 8" | 1024 x 768 | IIC |
| Capacitive | 10.1" | 1280 x 800 | USB |
| Capacitive | 10.1" | 2560 x 1600 | USB |
Camera
|
Model |
Resolution |
Type of Interface |
| Logitech C170 | 640 x 480 | USB |
| Logitech C270 | 1280 x 720 | USB |
| RC4K | 3840 × 2160 4K | USB/RJ45 |
Communication
|
Type |
Model |
Protocol |
Type of Interface |
| 3G | HUAWEI MU709s-2 HSPA+ Mini PCIe |
WCDMA/HSDPA/HSUPA/HSPA+: Band 1, Band 8, all bands with diversity GSM/GPRS/EDGE: 850 MHz/900 MHz/1800 MHz/1900 MHz |
PCIe |
| 4G | HUAWEI ME909s-821 LTE Mini PCIe |
FDD LTE:Band 1, Band 3, Band 8 TDD LTE: Band 39, Band 40, Band 41 (38) DC-HSPA+/HSPA+/HSPA/UMTS:Band 1, Band 9, Band 5, Band 8 TD-SCDMA: Band 34, Band 39 GSM/GPRS/EDGE: 1800MHz/900MHz |
PCIe |
| 4G | HUAWEI ME909u-521 Mini PCIe |
LTE (FDD) B1/B2/B3/B5/B7/B8/B20 DC-HSPA+/HSPA+/HSPA/UMTS dual-band B1/B2/B5/B8 EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz |
PCIe |
| 3G/4G | EC25 Series Mini PCIe |
FDD-LTE:B1/B3, TDD-LTE：B38/B39/B40/B41 WCDMA：B1, TD-SCDMA：B34/B39, CDMA：BC0 GSM900/1800, GPS/GLONASS |
PCIe |
Thermal Printer
|
Brand |
Model |
Width |
Type of Interface |
| Rongta | PM 628 | 58 mm |
RS232/USB |
| Masung | MS-D347 | 80 mm | USB |
| Masung | MS-D245 | 58 mm | RS232 |
Credit: Meet the Team Behind the Revolutionary Warp 3 Medical Recorder
Download (Log in first)
SanStar Android Medical Motherboard WS-3A Technical Specification
Development Manual SanStar WS-3A
System Customize Manual SanStar WS-3A Medical Motherboard
Warp 3 Medical Recorder CE Certificate
